A schematic shows an offshore tension-leg platform (TLP) for oil and gas production. The surface deck with cranes and processing units rests on large buoyant columns connected by pontoons. Long vertical tendons descend to anchors on the seabed, restraining vertical motion in deep water. Multiple risers run from the deck to subsea wells for drilling and production. The diagram highlights the mooring system, buoyancy elements, and overall deepwater platform architecture.
