A schematic from electrodynamics and accelerator physics shows a relativistic charged particle (yellow) following a helical path (black) around a straight guiding trajectory indicated by a red arrow in a magnetic field. The particle’s centripetal acceleration produces electromagnetic radiation, illustrated as blue wavy arrows emitted from the path. The diagram highlights helical motion, forward propagation, and radiation from high-energy charges, concepts fundamental to storage-ring light sources and certain astrophysical emitters.
