Rj45 connector cable 568a shape Illustration and Icon
Rj45 connector cable 568a shape
Log in to your account
Already a member? Do Login instead
The Rj45 connector cable 568a shape icon is the perfect fit for your brilliant infographic template. Build beautiful scientific, academic and educational infographics and presentations with this illustration, picture or drawing.
Customize the Rj45 connector cable 568a shape illustration or drawing as needed, if needed and download, present or share your work instantly. This template was made by scientists, for scientists.
A technical illustration depicts an 8P8C modular plug wired to a copper UTP patch cable using the ANSI/TIA-568A pinout. From pin 1 to 8, the conductors are white/green, green, white/orange, blue, white/blue, orange, white/brown, and brown. Hierarchically, the conductors reside within a twisted-pair cable that forms part of a structured cabling system. In electrical engineering and telecommunications, this connector type (RJ45, Registered Jack 45) enables Ethernet data transmission at the plug end of a local area network (LAN) cable.
