Diagram of a disposable invasive pressure transducer assembly used for IBP (invasive blood pressure) monitoring in clinical physiology and critical care. The device, a medical sensor within a hemodynamic monitoring system, shows a fluid-filled rigid transducer housing with integrated three-way stopcock, Luer-lock connectors, and a mounting bracket. Within this hierarchy, the stopcock controls the intravascular fluid column, while the transducer converts hydrostatic pressure into an electrical signal recorded in mmHg. The site of application is intravascular arterial or venous catheters.
